Konform® AR is ideal for providing insulation against high-voltage arcing and corona shorts. This extremely effective acrylic conformal coating provides a hard, durable protective barrier against humidity, salt, corrosive vapors and fungus for printed circuit board and electronic assemblies. Konform® AR resin meets MIL-I-46058C, Type AR.

Features
• No mixing is required
• Clear transparent coating
• Excellent dielectric strength
• Helps prevent arcing and shorts
• Increases life of electronic assemblies
• Plastic safe
• Provides excellent acid resistance
• Will not discolor over time under normal use
• Coating provides acid resistance is easily repairable
• Contains a UV indicator for thorough Quality Control inspection
• Flammable

• Ozone Safe  – CFC/HCFC free

Konform® AR CTAR-1 Specifications:
• Size: 11.5 oz. aerosol
• Color: clear, transparent
• Acrylic coating working temperature: -75°F/-59°C to 279°F/137°C
• High dielectric strengths of 1100 volts/mil or more.
• Tack Free Time: 30 min.
• Curing Conditions: 24 Hours @ 77°F (25°C)
(@ 80% R.H.) 8 Hours @ 170°F (77°C)
• High dielectric strength: 8300 volts/mil
• Easily repairable
• RoHS Compliant
• Meets Mil-I-46058C, Type AR, Compliant to IPC-CC-830A ,UL Recognized E76307
• Size: 1 gallon
