Soder-Wick’s pure copper braid has a unique geometric design that significantly reduces rework/repair time and minimizes the risk of heat damage to the board and sensitive components. Minimal flux residue on the board speeds up the cleaning process or eliminates it entirely.

Applications
• Medium pads

Features
•  Engineered specifically for high temperature, lead-free solders
•  Transfers heat to the solder joint quickly and efficiently
•  Can also be used with Tin/Lead solders
•  Non-corrosive ultra high purity no-clean flux
•  Will not leave ionic contamination on the boards
• ESD-safe static dissipative bobbins
•  RoHS Compliant

Specifications:

• Braid Size:  #3 Green

• Braid Width:  0.030″ (0.8mm)

• Braid Length: 5-feet

• Flux Type:  High-Temperature No-Clean Type ROL0

•  ANSI/IPC J STD-004, MIL-F-14256 F
• No Clean Flux Spec: MIL-STD-883B, Bellcore TR-NWT-000078, ANSI/IPC J SF818

• Manufacturers Standard Pack: 25 pcs.
