Teledyne Impulse’s longer length electrodes reach difficult-to-access areas such as instrumentation closures or wiring cabinets. Temperature controlled heat permits the user to limit the temperature for materials that burn, scorch or emit fumes. Stripper is designed to remove a variety of insulation types, quickly and easily, without nicking the conductor or damaging the existing insulation.

Features and Benefits:
• Longer length electrodes for difficult-to-access areas
• Longer strip lengths (up to 3-1/2″)
• Blades heat and cool instantly
• Ideal for high or low temperature insulation
• Ideal for Teflon, Kapton® ,Kynar® , rubber, nylon, vinyl, polypropylene and neoprene.
• Strip single, multi-strand or shielded wire
• Self-contained unit does not require a power source
• Wire gauge stop easily sets to desired wire strip length

• Optional blades are available for stripping extremely find wires (26-38 AWG)
• Table bench mount and notched blades #001-312-2 included (strip wires 10-25 AWG)

Specifications
• Teledyne Impulse TWC-2 StripAll
• Temp. Range: 100° – 1700° (F)
• Blade Temp: 1700° in 2 seconds, cools instantly
• Wire size: 10 – 38 AWG (1-1/2″ dia.)
• Electrode length: 3-1/2″
• Weight: 20 oz.
• Cord: 6 ft.
• Mil Spec, OEM, IPC-A-610

Replacement Blade Options – Important Information:
• Unit includes Notched Blades #001-312-2 (for stripping wires 10-25 AWG)
• Optional Blank Blades #001-312-1 (for stripping extremely fine wires 26-38 AWG) (Purchase Separately)
