A durable stainless steel probe for TH and SMT for pitch sizes above 25 mil.

Features & Benefits
• Perfect for aligning, straightening and cleaning of surface mount component leads and pads.

• Ergonomic hex handle
• Non-magnetic, conductive 300 Series stainless steel
• Stainless steel won’t corrode – no problem in working with magnetized parts
• Any charge can be grounded when placed on ESD protected work surface

• Semi-hardened points may be reshaped for special applications as required
• ESD Protective: Any charge can be grounded when placed on ESD protected work surface
• Made in the USA

Specifications:
• Length: 5-1/2″
• Point style: Straight

• Material: 300 series stainless steel
• Handle Diameter: .156″ (3.96mm) ± .003″
• Points Semi hardened – may be reshaped for special applications as required
• Pin Diameter: .048″ (1.22mm) ± .001″
• Pin Tip Diameter: .010″ – .020″ (.254mm – .508mm) ± .001″
