Teledyne Impulse stripper is designed to remove a variety of insulation types, quickly and easily, without nicking the conductor or damaging the existing insulation. Temperature controlled heat permits the user to limit the temperature for materials that burn, scorch or emit fumes.

Stripall TWC-1 Features & Benefits:

• Strip high or low temp insulation as well as Teflon®, Kapton®, nylon, vinyl and neoprene
• Blades heat and cool instantly
• Strip single, multi-strand or shielded wire
• Self-contained unit eliminates the need for a bulky bench-top power supply.
• Easily adjust to the desired wire strip length

• Optional blades are available for stripping extremely fine wires (26+38 AWG)
• Table bench mount and notched blades #001-312-2 included (strip wires 10-25 AWG)

Specifications
• Part No.: Teledyne Impulse TWC-1 StripAll
• Strip insulation up to 1-1/2″ dia. (10-38AWG)
• Temp. Range: 100° – 1700° (F)
• Blade Temp: 1700° in 2 seconds, cools instantly
• Electrode length: 1-1/2″
• Weight: 20 oz.
• Cord: 6 ft.
• Mil Spec, OEM, IPC-A-610

Replacement Blade Options – Important Information:
• Unit includes Notched Blades #001-312-2 (for stripping wires 10-25 AWG)
• Optional Blank Blades #001-312-1 (for stripping extremely fine wires 26-38 AWG) (Purchase Separately)
